Made in Taiwan since 2008 · CE / FCC / RoHS

See inside the engine without taking it apart.

Articulating, dual-lens and industrial borescopes for aircraft, turbines, engines and pipelines. 2 to 25 mm probes, built in Taiwan and shipped worldwide.

TX5-T41D borescope inspecting an engine

2008

Founded in Taiwan

16

Borescope models in 5 families

USD 5M

Annual turnover

CE · FCC · RoHS

Certified, shipped worldwide

Five borescope families. One inspection partner.

From 2 mm articulating probes to 25 mm pipe cameras. Pick by access size and how much you need to see.

TL5-T2A62D 2-way articulating dual-lens borescope with 5-inch screen

2-way articulating borescopes

Turbines, engines, aerospace

Probe

6–6.5 mm

Steering

2-way

Lens

Single / dual

Length

2–3 m

View 2-way models →

TJ5-TJ551D 4-way joystick articulating dual-lens borescope with 5.5 mm probe

4-way joystick borescopes

Aerospace, gas turbines, precision parts

Probe

2–6.5 mm

Steering

4-way, ≥120°

Lens

Dual (TJ5)

Screen

5–6″

View 4-way models →

TX5-T41D dual-lens borescope with 5-inch screen

Dual-lens borescopes

Heat exchangers, engines, pipes

Probe

4 / 9 mm

View

Front + side

Length

1 m

Screen

3.5–5″

View dual-lens models →

TH500-4100 video borescope with 3.5-inch screen and 4 mm probe

Industrial videoscopes

Automotive, HVAC, maintenance

Probe

3.7–8.5 mm

Length

1–5 m

Screen

3.5–4.3″

Models

6

View videoscopes →

TX101-2520W pipe inspection camera with 25 mm camera head and cable reel

Pipe inspection cameras

Drains, pipelines, municipal pipes

Camera

25 mm

Lighting

12 white LEDs

Model

TX101-2520W

Unit

Cable reel

View pipe cameras →

Built for the places you can’t open up.

Highlights across the Texim range.

Dual-lens technology

Front and side view from one probe. No blind spots.

2 mm

Slimmest articulating probe

4-way

Joystick articulation, ≥120°

TH100-T2A62U 6 mm articulating camera tip with LEDs

1080p

Full HD video recording

128 GB

Maximum TF card storage

6″

FHD touchscreen on TP6-2010

8 h

Battery life on TP6-2010

CE · FCC · RoHS

Certified for export

Where our scopes work

Visual inspection where dismounting is too slow or too costly.

Technician using the TH500-4100 to inspect an aircraft engine

Aircraft

Turbine blades, combustors, gearboxes

TP37100 video borescope used for engine inspection

Engines & turbines

Cylinders, valves, industrial gas turbines

TX101-2520W pipe inspection camera at a pipeline

Pipes & plumbing

Drains, HVAC ducts, municipal pipelines

Which probe fits your access hole?

Choose a probe smaller than the smallest opening it must pass through. Articulating probes need extra room to bend. Not sure? Send us the opening size.

Ask an engineer

Probe

Type

Models

2 mm

4-way articulating, fiber-optic

TP6-2010

3.7–4 mm

Single lens

TP37100, TH500-4100

4 mm

Dual lens

TX5-T41D, TJ5-TJ41D (4-way)

4.5 mm

Single lens, semi-rigid

TP45100

5.5 mm

Single lens

TH100-T6002

5.5 mm

Dual lens, 4-way

TJ5-TJ551D

6 mm

Single lens, 2-way

TC5-T2A62, TH100-T2A62U

6.5 mm

Dual lens, 2-way / 4-way

TL5-T2A62D, TH100-T2A63D, TJ5-TJ61D

8.5–9 mm

Single / dual lens

TH500-85100, TP-D9100

25 mm

Pipe camera

TX101-2520W

Frequently asked questions

Which probe size do I need?

Choose a probe smaller than the smallest opening it must pass through; articulating probes need extra room to bend. Our probes range from 2 mm to 25 mm. Send us the opening diameter and we will recommend a model.

What probe lengths are available?

Probe length depends on the model, from 1 m to 3 m on most scopes. The TH500-4100 series is available in 1, 2, 3 and 5 m. Contact us if you need a different length.

What is the minimum order quantity?

The MOQ is 10 units per model, packed 10 units per carton.

Can I order a sample first?

Yes. Samples are available; the buyer covers the sample cost, shipping and taxes.

What is the lead time and where do you ship?

Standard lead time is about 2 weeks, FOB Taiwan. We ship to customers across Asia, Australia, North America, Western Europe and the Middle East.

Which certifications do your products have?

Our borescopes are CE, FCC and RoHS certified.

Tell us the application. We’ll spec the probe.

Reply within one business day from our Taipei office. OEM and private-label welcome.

sales@texim-taiwan.com

+886-931-656-155

Mr. Kasper Chou, Overseas Sales
